Cell

Mono

Weight

32.5kg

Dimensions

2333±2mm×1134±2mm×30±1mm

Cable Cross Section Size

4mm²(IEC)，12 AWG(UL)

No. of cells

144(6×24)

J-Box

IP68, 3 diodes

Connector

QC 4.10-351/ MC4-EVO2A

Front Glass/Back Glass

2.0mm/2.0mm

Nominal Max. Power (Pmax)

555w

560w

565w

570w

575w

580w

Power Tolerance

0~±3%

Open Circuit Voltage(Voc) [V]

50.14

50.32

50.5

50.68

50.86

51.04

Maximum Power Voltage(Vmp) [V]

41.29

41.49

41.68

41.87

42.05

42.24

Short Circuit Current(lsc) [A]

14.19

14.25

14.31

14.37

14.44

14.5

Maximum Power Current(lmp) [A]

13.44

13.5

13.56

13.62

13.67

13.73

Module Efficiency[%]

21.00%

21.20%

21.40%

21.50%

21.70%

21.90%
